Electronic level sensor ifm electronic LK1024 UAE

Brand :

Stock Status : Contact us for delivery

Brand :

Stock Status :

Out of Stock

Part Number : LK1024

The electronic level sensor LK1024 from ifm electronic is working with a capacitive measuring principle. The sensor is optimized for use in water-based coolants and oils for machine tools and hydraulic power packs. Thanks to the probe length of 728 mm, the level sensor LK1024 is optimal for medium-sized tanks. The current level is displayed clearly visible on the 4-digit alphanumeric display. With one of the digital switching outputs a 2-point level control can be realized. The second output can be used as dry run protection or for an overflow alarm.

Specification
Features
Catalog
Youtube

Specifications

Details

Operating voltage [V]

18-30 DC V

Overload protection

yes

Short-circuit protection

yes

Reverse polarity protection

yes

Current consumption [mA]

<50

System

gold-plated contacts

Output function

normally open / closed; (configurable)

Electrical design

PNP/NPN

Weight

545g
