Brannan 10/409/0 | BS 718 M100 SP Density Hydrometer | 1.50–1.60 g/ml, 250 mm
Part number 10/409/0 identifies the Brannan M100 SP density hydrometer graduated from 1.50 to 1.60 g/ml to BS 718:1991. On the 10/409/0, graduations fall every 0.002 g/ml over a 0.100 g/ml span, with adjustment at 20 °C and an overall length of 250 mm. The 10/409/0 offers 0.002 g/ml accuracy, tighter than a standard M100 hydrometer, because it belongs to the SP sub-series.
Key features
- Range 1.50 to 1.60 g/ml
- 0.002 g/ml divisions over a 0.100 g/ml span
- 250 mm overall length, 18–20 mm bulb diameter
- Adjusted at 20 °C
- Accuracy 0.002 g/ml, higher than the standard M100 series
- Made in the UK, supplied in a resealable protective tube
Certification options for the 1.50–1.60 g/ml M100 SP hydrometer from Brannan are UKAS certification, a certificate traceable to a recognised national standard, or a statement of conformity.
- Specifications
- Features
- Downloads
| Part Number | 10/409/0 |
| Brand | Brannan |
| Series | M100 SP |
| Standard | BS 718:1991 (generally aligned with ISO 387 and ISO 649) |
| Density Range | 1.50–1.60 g/ml |
| Range Span | 0.100 g/ml |
| Divisions | 0.002 g/ml |
| Accuracy | 0.002 g/ml |
| Overall Length | 250 mm |
| Bulb Diameter | 18–20 mm |
| Approx. Weight | 42 g (incl. 14 g protective tube) |
| Adjustment Temperature | 20 °C |
| Material | Soda glass, steel shot ballast, synthetic wax resin |
| Country of Manufacture | UK |
- 190mm long, Series S50, with range spans of 0.050g/ml and 0.002g/ml
- 270mm long, Series M50, with range spans of 0.050g/ml and 0.001g/ml
- 330mm long, Series L50, with range spans of 0.050g/ml and divisions of 0.0005g/ml
- UKAS or a traceable calibration certificate may be provided.
