Brannan 10/949/0 | Specific Gravity Hydrometer, M100 Series | 1.50 to 1.60 SG, 250 mm
Part Number : 10/949/0
Covering 1.50 to 1.60 SG, the Brannan 10/949/0 belongs to the M100 series of general purpose specific gravity hydrometers. With a band of 1.50 to 1.60, it is used for liquids denser than water, giving relative density against water. Adjusted at 60 °F (15.6 °C), the M100 model 10/949/0 measures 250 mm overall and spans 0.100 SG with 0.002 SG divisions. Like the other M100 instruments, the 10/949/0 is similar to hydrometers in ISO 650 and in the now superseded 1960 issue of BS 718.
Key features
- Range 1.50 to 1.60 SG on the 60/60 °F specific gravity scale
- 0.002 SG divisions, accuracy 0.002 SG, 0.100 SG range span
- Overall length 250 mm with 18–20 mm bulb
- Soda glass body, steel shot ballast, synthetic wax resin
- 1.50–1.60 SG scale made to suit liquids of medium surface tension
- UK-made; delivered in a resealable protective plastic tube
Brannan can supply the 10/949/0 with a UKAS calibration certificate, a certificate traceable to a recognised national standard, or a Statement of Conformity.
For pricing, please contact our experts.
