CONCOA 5342922-01-001 | 534 Series Adjustable Relief Valve | Brass, FKM Seals, 20-100 PSIG Relief
Part Number : 5342922-01-001
Set within 20-100 PSIG (1.4-7 BAR), the CONCOA 5342922-01-001 adjustable relief valve combines a brass barstock body with FKM seals. Use it on regulators, line systems or distribution systems; once 20-100 PSIG set pressure is exceeded the seat lifts and vents the excess.
Key features
- Connections for the 20-100 PSIG brass/FKM version: 1/4 in MNPT in, 1/4 in FNPT out
- Cv of 0.37 for the 20-100 PSIG brass/FKM version
- Relief point of the 20-100 PSIG brass/FKM version is factory set and simple to readjust
- Stainless steel spring and poppet in the 20-100 PSIG brass/FKM version
For pricing, please contact our experts.
