CONCOA 5512101-01-1 | 551 Series Cryogenic Vapor Vent | 1/2 in Male Bayonet Inlet
Part Number : 5512101-01-1
CONCOA 5512101-01-1 is a vacuum insulated 551 Series cryogenic vapor vent with a 1/2 in male bayonet inlet. As a keep-full device it lets boil-off gas escape while holding liquid in a vacuum-insulated pipe system, keeping liquid nitrogen on demand close to the point-of-use. The tube-style bayonet inlet makes later expansion of the piping system easier.
Key features
- Mechanical float valve on the bayonet model works without electrical or pneumatic assistance
- Bayonet-inlet unit has a vacuum-insulated float assembly that resists frost and ice build-up
- Check valve allows flow in one direction only, protecting the bayonet-connected piping
- Stainless steel wetted parts; 1/2 in FNPT outlet; 150 PSIG (10 BAR) max working pressure
For pricing, please contact our experts.
