CONCOA 5803034 | 580 Series Toxic Gas Detector | Fluorine Sensor
CONCOA sensor 5803034 detects fluorine and is used with the 5803030 universal toxic gas controller. Sensor status is monitored continuously, and the cell can be recharged or replaced when needed. Fluorine levels are reported on the controller's digital display, and the 90 dB horn sounds above the alarm threshold.
- Target gas: fluorine (plug-in sensor for the 5803030 controller)
- Alarms through a 90 dB horn and LED indicators
- Operates from -32 °C to 50 °C with a 3-8 year sensor life
- Specifications
- Downloads
| Part Number | 5803034 |
| Brand | CONCOA |
| Series | 580 Series Toxic and Corrosive Gas Detector |
| Accuracy | ±10% of full scale |
| Sensor Type | Renewable electrochemical |
| Analog Output | 4-20 mA |
| Power | 250 mA @ 24 VDC |
| Enclosure | Polycarbonate |
| Conformances | CE, UL/cUL |
| Gas | Fluorine |
| Requires | 5803030 controller |
| Sampling Method | Diffusion |
| Sensor Life | 3-8 years |
