CONCOA 5803049-01-1 | 580 Series Gas Detector | Butadiene/Isobutane LEL Detector
The CONCOA 5803049-01-1 is an LEL detector/transmitter for butadiene and isobutane. It reports flammable concentration as a percentage of the lower explosive limit, giving early warning before an atmosphere becomes ignitable. The detector can operate on its own or report to a 585 Series ESO controller or a 4- or 8-channel controller.
- Gas detected: Butadiene / isobutane (LEL)
- Operates on 24 VDC between -20 °C and 60 °C
- Continuous self-testing alerts the user to faults or electrical degradation
- Specifications
- Downloads
| Part Number | 5803049-01-1 |
| Brand | CONCOA |
| Series | 580 Series Universal LEL Gas Detector |
| Operating Temperature | -4 to 140 °F (-20 to 60 °C) |
| Weight | 6.5 lb (3 kg) |
| Analog Output | 4-20 mA |
| Power | 24 VDC |
| Enclosure | NEMA 4 explosion-proof |
| Gas Detected | Butadiene / isobutane (LEL) |
| Relay Outputs | 2 alarm relays, 1 fault relay, ≤2 A @ ≤24 VDC |
