CONCOA 8064578-01-1 | Medical Air Flowmeter Regulator | CGA 346-H, 1-15 LPM, DISS 1240
Fitted with a CGA 346-H cylinder inlet and DISS 1240 outlet, the CONCOA 8064578-01-1 medical air flowmeter regulator gives a 1-15 LPM flow range. Gauging on 8064578-01-1: 0-15 LPM flowmeter and 0-4000 PSIG inlet gauge.
- Sintered bronze filtration at 25 microns and PTFE seat material for long service life
- Large, easy-to-read colour-coded gauges and US FDA listing for therapy
- No European medical CE listing and CRN OH5216.5R2 registration
- Specifications
- Downloads
| Part Number | 8064578-01-1 |
| Brand | CONCOA |
| Series | Medical Air Regulator |
| Regulator type | Flowmeter Regulator |
| Inlet connection | CGA 346-H |
| Flow range | 1-15 LPM |
| Outlet connection | DISS 1240 |
| Flowmeter / gauges | 0-15 LPM Flowmeter and 0-4000 PSIG Inlet Gauge |
| Max inlet pressure | 3000 PSIG (210 BAR) |
| Body | Chrome-plated brass barstock |
| Gauges | 2 in (50 mm) diameter plated case |
| Seat | PTFE |
| Conformances | Cleanliness meets or exceeds CGA G-4.1; ANSI/ASME B40.1; CRN OH5216.5R2 |
