CONCOA 8066599-01-1 | 6590 Series Pipeline Regulator | Fuel Gas, CGA 025, 40 PSIG Delivery
Part Number : 8066599-01-1
The fuel gas point-of-use pipeline regulator from CONCOA (8066599-01-1) uses a CGA 025 inlet and 9/16 in -18 (B) LH Ext outlet. Maximum delivery is 40 PSIG (3 BAR) for fuel gas; the gauge is scaled 0-60 PSIG/0-400 kPa.
Key features
- A chrome-plated, die-cast zinc bonnet with a forged brass body
- A chloroprene diaphragm for steady pressure control with a 200 PSIG (14 BAR) maximum inlet pressure
- A CAPSULE® seat design for easy maintenance and a medium-large seat displacement that supports high flow
- A brass outlet gauge of 2 1/2 in (63 mm) and a 25-micron sintered bronze inlet filter
For pricing, please contact our experts.
