CONCOA 8066692-01-1 | 6690 Series Pipeline Regulator | Non-corrosive Gas, 40 PSIG Delivery, 3000 PSIG Inlet
The CONCOA 8066692-01-1 handles non-corrosive gases in pipeline service at inlet pressures to 3000 PSIG (210 BAR). A 0-60 PSIG/0-400 kPa gauge shows outlet pressure, which reaches 40 PSIG (3 BAR) at most.
Key features
- A 1/4 in MNPT outlet with a 2 1/2 in (63 mm) brass gauge
- Brass barstock body and bonnet, plus a 1/4 in FNPT inlet
- A PTFE seat in a CAPSULE® design with a chloroprene diaphragm for steady pressure control
- A 40-micron sintered bronze filter and a Cv of 0.2
- Specifications
- Downloads
| Part Number | 8066692-01-1 |
| Brand | CONCOA |
| Series | 6690 Series Pipeline Regulator |
| Body | Brass barstock |
| Seat | PTFE |
| Gas Service | Non-corrosive |
| Max Inlet Pressure | 3000 PSIG (210 BAR) |
| Filter | 40-micron sintered bronze |
| Bonnet | Brass barstock |
| Max Delivery Pressure | 40 PSIG (3 BAR) |
| Diaphragm | Chloroprene |
| Temperature Range | -40 °F to 140 °F (-40 °C to 60 °C) |
| Outlet Gauge | 0-60 PSIG/0-400 kPa |
| Gauge | 2 1/2 in (63 mm) diameter brass |
