CONCOA 8066693-01-1 | 6690 Series Pipeline Regulator | Non-corrosive Gas, 120 PSIG Delivery, 3000 PSIG Inlet
For non-corrosive gases pipelines, CONCOA 8066693-01-1 accepts up to 3000 PSIG (210 BAR) at the inlet. Maximum delivery is 120 PSIG (8 BAR), with the outlet gauge scaled 0-200 PSIG/0-1400 kPa.
Key features
- Brass barstock body and bonnet with a chloroprene diaphragm for steady pressure control
- A PTFE seat in a CAPSULE® design with a 1/4 in FNPT inlet
- A 40-micron sintered bronze filter with a 1/4 in MNPT outlet
- A brass outlet gauge of 2 1/2 in (63 mm) and a Cv of 0.2
- Specifications
- Downloads
| Part Number | 8066693-01-1 |
| Brand | CONCOA |
| Series | 6690 Series Pipeline Regulator |
| Body | Brass barstock |
| Seat | PTFE |
| Gas Service | Non-corrosive |
| Max Inlet Pressure | 3000 PSIG (210 BAR) |
| Filter | 40-micron sintered bronze |
| Bonnet | Brass barstock |
| Max Delivery Pressure | 120 PSIG (8 BAR) |
| Diaphragm | Chloroprene |
| Temperature Range | -40 °F to 140 °F (-40 °C to 60 °C) |
| Outlet Gauge | 0-200 PSIG/0-1400 kPa |
| Gauge | 2 1/2 in (63 mm) diameter brass |
