CONCOA 8066754-01-1 | 6700 Series Manifold Regulator | CO2/Inert Gas, 200 PSIG Delivery, RH Inlet
Part Number : 8066754-01-1
Part 8066754-01-1 is the RH-inlet 6700 Series manifold regulator set up for carbon dioxide and inert gas. Maximum delivery is 200 PSIG (14 BAR); the seat is EPDM and the gauges read 0-400 PSIG/0-2800 kPa and 0-4000 PSIG/0-28,000 kPa.
Key features
- A 3000 PSIG (210 BAR) maximum inlet rating without peripherals, plus 1/4 in FNPT gauge and relief ports
- A brass barstock body with a balanced stem seat that steadies output as inlet pressure decays
- A rugged forged brass bonnet and 1/2 in FNPT inlet and outlet ports
- A 316L stainless steel filter rated at 40 micron with a diaphragm of chloroprene
For pricing, please contact our experts.
