CONCOA 8410158 | Industrial Flow Gauge | 0-200 SCFH, 1.5 in, 1/8 in MNPT
Reading 0-200 SCFH with 25 SCFH increments, CONCOA 8410158 is a 1.5 in industrial flow gauge. This 0-200 SCFH gauge connects through 1/8 in MNPT and is housed in a polished brass case.
Key features
- A shatter-resistant polycarbonate window, together with cleanliness that meets or exceeds CGA G-4.1
- Conformance with ANSI/ASME B40.1, plus spring-suspended pin movement for reliability and durability
- Grade B accuracy of ±3/2/3% of full scale as well as bottom or centre back mounting for straightforward installation
- Specifications
- Downloads
| Part Number | 8410158 |
| Brand | CONCOA |
| Series | Industrial Gauges |
| Range | 0-200 SCFH |
| Connection | 1/8 in MNPT |
| Case | Polished brass |
| Dial Size | 1.5 in |
| Accuracy | Grade B ±3/2/3% of full scale |
| Window | Shatter-resistant polycarbonate |
| Description | 1.5 in Diameter, 1/8 in MNPT, Polished Brass Case |
| Increments | 25 SCFH |
| Conformances | CGA G-4.1 cleanliness; ANSI/ASME B40.1 |
