CONCOA 8410207 | Industrial Pressure Gauge | 0-4000 PSIG, 1.5 in, 1/8 in MNPT
CONCOA 8410207 is a 1.5 in industrial pressure gauge reading 0-4000 PSIG in 500 PSIG increments. The 1.5 in dial has a 1/8 in MNPT connection in a back-mount configuration and a polished brass case for industrial gas service.
Key features
- Spring-suspended pin movement for reliability and durability, together with cleanliness that meets or exceeds CGA G-4.1
- Grade B accuracy of ±3/2/3% of full scale and conformance with ANSI/ASME B40.1
- Specifications
- Downloads
| Part Number | 8410207 |
| Brand | CONCOA |
| Series | Industrial Gauges |
| Range | 0-4000 PSIG |
| Connection | 1/8 in MNPT (back mount) |
| Case | Polished brass |
| Dial Size | 1.5 in |
| Accuracy | Grade B ±3/2/3% of full scale |
| Window | Shatter-resistant polycarbonate |
| Description | 1.5 in Diameter, 1/8 in MNPT (back mount), Polished Brass Case |
| Increments | 500 PSIG |
| Conformances | CGA G-4.1 cleanliness; ANSI/ASME B40.1 |
