DeFelsko STDCSS | Certified Plastic Shims Complete Set | 8 Shims, 25 to 1500 µm
The DeFelsko STDCSS is the complete set of eight certified plastic shims, CS1 through CS60, covering approximately 25 µm (1 mil) to 1500 µm (60 mils). The colour-coded shims provide an economical alternative to coated metal plates for verifying electronic magnetic, eddy-current and ultrasonic coating thickness gauges across their range.
Key features
- 8 shims: 25, 50, 75, 125, 250, 500, 1000 and 1500 µm (approx.)
- Accuracy: ±2 µm (±0.08 mil)
- Each shim 3 x 8 cm (1 x 3 in) in its own protective sleeve
- Certificate of Calibration included with the set
- Labelled in metric and imperial units
- Not suitable for magnetic pull-off gauges
- Specifications
| Part Number | STDCSS |
| Brand | DeFelsko |
| Accuracy | ±2 µm (±0.08 mil) |
| Certification | Certificate of Calibration |
| For Use With | Type 2 electronic coating thickness gauges |
| Set Size | 8 shims (CS1, CS2, CS3, CS5, CS10, CS20, CS40, CS60) |
| Thickness Range | Approx. 25 to 1500 µm (1 to 60 mils) |
| Shim Size | 3 x 8 cm (1 x 3 in) |
