Desoutter QST62-230MCOT-T50-L152-H19 | Off-Set Fixtured Nutrunner | 23-230 Nm, 465 r/min, 3/4" square
Part Number : 8435626520
The Desoutter QST62-230MCOT-T50-L152-H19 (part number 8435626520) is a QST-M off-set fixtured nutrunner rated from 23 Nm (17 ft lb) to 230 Nm (170 ft lb), with a top speed of 465 r/min and a gear ratio of 19.04. Built for automated, high-volume assembly lines, the QST62-230MCOT-T50-L152-H19 uses the newly developed QST-M motor and transducers. This version has a 3/4" male square output, an E dimension of 647 mm, an A dimension of 152.5 mm and 50 mm of travel and weighs 13.9 kg (30.6 lb).
Key features
- 23-230 Nm torque range on the QST62-230MCOT-T50-L152-H19 with torque scatter (3s) of 2.5% or less
- 1500 W motor on a 570 V three-phase AC supply, 19.04 gear ratio, up to 465 r/min
- QST62-230MCOT-T50-L152-H19: 3/4" square male drive, Min C-C 45
- QST-M family benefit for the QST62-230MCOT-T50-L152-H19: no external PLC needed
- High reliability and low maintenance cost stated for QST-M (QST62-230MCOT-T50-L152-H19)
For pricing, please contact our experts.
