Dwyer 628-00-GH-P1-E1-S1 | Pressure Transmitter | 0-15 psia, 628 Series

Name: Dwyer 628-00-GH-P1-E1-S1 | Pressure Transmitter | 0-15 psia, 628 Series
Brand: Dwyer
SKU: 628-00-GH-P1-E1-S1
Availability: InStock

Part Number : 628-00-GH-P1-E1-S1

The Dwyer 628-00-GH-P1-E1-S1 is a Series 628 pressure transmitter for 0-15 psia, designed for OEMs with a sensor accurate to 1% of full scale. Corrosion-resistant 316L stainless steel wetted parts let it measure processes from hydraulic oils to chemicals.

0-15 psia range; sensor accuracy 1% of full scale
Wetted parts in corrosion-resistant 316L stainless steel
10-30 V supply; 38 mA current consumption
1/4 in (0.25 in) port size (628-00-GH-P1-E1-S1)
4-1/2 digit LCD
Ambient temperature -18 to 79 °C; CE

Availability: low stock

Free UAE shipping available

Specifications
Features
Downloads

Part Number	628-00-GH-P1-E1-S1
Brand	Dwyer
Range	0-15 psia
Series	628
Accuracy	1% FS
Wetted Parts	316L stainless steel
Supply Voltage	10-30 V
Current Consumption	38 mA
Port Size	0.25 in
Display	4-1/2 digit LCD
Ambient Temperature	-18 to 79 °C
Standards	CE

Sturdy, oil-filled 316L stainless steel sensor resists stress and vibration, ensuring steady pressure control for process applications.
When it comes to dust and particle matter, especially in tough environments where exterior monitoring is allowed, a NEMA 4X rated enclosure offers protection.
many models and connections that can satisfy modest to extremely high pressure measuring requirements.
