Dwyer DAW-23-153-10S | Weatherproof Bourdon Tube Pressure Switch | 25-600 psig | 403 SS | SPDT
Part Number : DAW-23-153-10S
Dwyer DAW-23-153-10S is a weatherproof Bourdon tube pressure switch for 25 to 600 psig, with a 403 stainless steel element and an SPDT contact rated 120-240 V AC/DC. It is bottom mounted on a 1/4 in male NPT connection and rated to 180 °F (82 °C). Repeatability of the DAW-23-153-10S is within ±1% of the working range, and it can be installed vertically.
- Weatherproof enclosure
- Thumbscrew set point adjustment
- Screw terminal wiring
- CSA and UL approvals, 6 lb
Free UAE shipping available
For pricing, please contact our experts.
