Dwyer RHP-2D2F | Duct Mount RH/Temperature Transmitter | 2% RH, 0-10 VDC RH, 20K NTC Thermistor Output

Name: Dwyer RHP-2D2F | Duct Mount RH/Temperature Transmitter | 2% RH, 0-10 VDC RH, 20K NTC Thermistor Output
Brand: Dwyer
SKU: RHP-2D2F
Availability: InStock

Part Number : RHP-2D2F

The Dwyer RHP-2D2F is a 2% duct mount RH/temperature transmitter with a 0-10 VDC humidity output and a 20K NTC thermistor temperature output. This 0-10 VDC, 20K NTC thermistor version is powered from 15-35 VDC or 15-29 VAC and uses a capacitance polymer sensing element with a 15 second response.

Humidity signal: 0-10 VDC
20K NTC thermistor temperature output
±0.36°F at 77°F thermistor accuracy; power 15-35 VDC or 15-29 VAC
<1% RH/year drift; 15 s response time, ±1% hysteresis
NEMA 4X (IP66) electronics housing

Availability: low stock

Free UAE shipping available

Specifications
Features
Downloads

Part Number	RHP-2D2F
Brand	Dwyer
Mounting	Duct
RH Accuracy Class	2%
Output	0-10 VDC (RH)
Temperature Output	20K NTC thermistor (passive)
Thermistor Accuracy	±0.2°C @ 25°C (±0.36°F @ 77°F)
Power	15-35 VDC or 15-29 VAC
Sensor	Capacitance polymer
Response Time	15 s
Drift	<1% RH/year
Compensated Range	-4 to 140°F (-20 to 60°C)
Enclosure Rating	NEMA 4X (IP66), housing
Approvals	CE

Lower installation costs when temperature and humidity are combined.
With 2%, 3%, and 5% accuracy and a wide range of temperature sensors, there is a wide application environment.
Lower system operating costs thanks to the radiation barrier that shields the sensor from heat radiation.
