Dwyer RHP-3E40 | Wall Mount Humidity Transmitter | ±3% RH, European

Name: Dwyer RHP-3E40 | Wall Mount Humidity Transmitter | ±3% RH, European
Brand: Dwyer
SKU: RHP-3E40
Availability: InStock

Part Number : RHP-3E40

Rated ±3% (20 to 80% RH @ 25°C), the Dwyer RHP-3E40 mounts on European-style walls, with a universal current/voltage output for relative humidity only. Air passes through the vented RHP-3E40 housing over its recoverable capacitive polymer sensor.

Switch selectable RH or dew point output, normal or reverse action on the RHP-3E40
Supply 10-35 VDC (4-20 mA) or 15-35 VDC / 15-29 VAC (0-5/10 V) (RHP-3E40)
RHP-3E40: Response 8 s; drift <0.25% RH/year; hysteresis ±0.8%
Polycarbonate IP20 housing, 4.4 oz (125 g) on the RHP-3E40

Availability: low stock

Free UAE shipping available

Specifications
Features
Downloads

Part Number	RHP-3E40
Brand	Dwyer
Series	RHP-E/N
Mounting	European wall mount
RH Accuracy	±3% (20 to 80% RH @ 25°C)
RH Range	0 to 100% RH
Outputs	Universal current/voltage RH
Power	10-35 VDC (4-20 mA); 15-35 VDC or 15-29 VAC (0-5/10 V)
Response Time	8 s
Drift	<0.25% RH/year
Enclosure	Polycarbonate, IP20
Weight	4.4 oz (125 g)

Lower installation costs when temperature, humidity/dew point, and sensing are integrated.
With a wide range of temperature sensors and 2% and 3% accuracy, there are many application scenarios.
Inventory was reduced thanks to field-selectable output.
