Dwyer SFI-350SS-1/2 | Sight Flow Indicator | 1/2" Body, Double Window, No Indicator
Part Number : SFI-350SS-1/2
With a 1/2" threaded body and a double viewing window with no moving indicator, the Dwyer SFI-350SS-1/2 gives a direct view of flow in the pipe. For servicing, the SFI-350SS-1/2 window can be removed and parts replaced.
- Dimensions of the 1/2" size: 4.063" (103 mm) long, 2.750" (70 mm) deep, 2.563" (65 mm) high (SFI-350SS-1/2)
- SFI-350SS-1/2 weight: 2.6 lb (1.2 kg)
- Rated to 125 psig (8.62 bar) on the SFI-350SS-1/2, 150 psig (10.34 bar) on MP models
- SFI-350SS-1/2 temperature limit 200°F (93°C); 120°F (48°C) with W2 option, 170°F (77°C) with I1 option
- Wetted parts for SFI-350SS-1/2: tempered glass window, bronze or 316 SS body (series options), Buna-N, fluoroelastomer or PTFE gasket
