Dwyer SFI-350SS-1/4 | Sight Flow Indicator | 1/4" Body, Double Window, No Indicator
Part Number : SFI-350SS-1/4
Dwyer's SFI-350SS-1/4 sight flow indicator has a 1/4" threaded body and a double viewing window with no moving indicator to show flow at a glance. For servicing, the SFI-350SS-1/4 window can be removed and parts replaced.
- Dimensions of the 1/4" size: 3.063" (78 mm) long, 2.250" (57 mm) deep, 2.125" (54 mm) high (SFI-350SS-1/4)
- SFI-350SS-1/4 weight: 1.7 lb (0.8 kg)
- SFI-350SS-1/4 pressure limit 125 psig (8.62 bar); MP models 150 psig (10.34 bar)
- SFI-350SS-1/4 temperature limit 200°F (93°C); 120°F (48°C) with W2 option, 170°F (77°C) with I1 option
- Wetted parts for SFI-350SS-1/4: tempered glass window, bronze or 316 SS body (series options), Buna-N, fluoroelastomer or PTFE gasket
