Dwyer SFI-350SS-3/8 | Sight Flow Indicator | 3/8" Body, Double Window, No Indicator
Part Number : SFI-350SS-3/8
Dwyer SFI-350SS-3/8: a 3/8" sight flow indicator with threaded process connections and a double viewing window with no moving indicator, for checking flow by eye. The window on the SFI-350SS-3/8 detaches for maintenance and part replacement.
- Dimensions of the 3/8" size: 3.063" (78 mm) long, 2.250" (57 mm) deep, 2.125" (54 mm) high (SFI-350SS-3/8)
- SFI-350SS-3/8 weight: 1.7 lb (0.8 kg)
- Rated to 125 psig (8.62 bar) on the SFI-350SS-3/8, 150 psig (10.34 bar) on MP models
- SFI-350SS-3/8 temperature limit 200°F (93°C); 120°F (48°C) with W2 option, 170°F (77°C) with I1 option
- Wetted parts for SFI-350SS-3/8: tempered glass window, bronze or 316 SS body (series options), Buna-N, fluoroelastomer or PTFE gasket
Free UAE shipping available
For pricing, please contact our experts.
