Dwyer VFA-41-BV | Visi-Float Acrylic Flowmeter | 0.6-5 GPH Water, 2" Scale, 5% FS

Name: Dwyer VFA-41-BV | Visi-Float Acrylic Flowmeter | 0.6-5 GPH Water, 2" Scale, 5% FS
Brand: Dwyer
SKU: VFA-41-BV
Availability: InStock

Part Number : VFA-41-BV

Part number VFA-41-BV is a Dwyer Visi-Float flowmeter scaled 0.6-5 GPH water, built around a transparent machined acrylic body and a 2" (51 mm) scale. The VFA-41-BV mounts vertically and connects through a 1/8" female NPT process port.

4.0 to 4.8 oz (0.11 to 0.14 kg) weight
Vertical mounting
RoHS II (2011/65/EU) compliant
Rated accuracy of 5% FS
1/8" female NPT process connection
Without valve: 150 psig (10 bar) at 100 °F (38 °C) or 100 psig at 150 °F

Availability: low stock

Free UAE shipping available

Specifications
Features
Downloads

Part Number	VFA-41-BV
Brand	Dwyer
Type	Visi-Float Flowmeter
Range	0.6-5 GPH water
Accuracy	5% of full scale
Scale Length	2" (51 mm)
Process Connection	1/8" female NPT
Wetted Materials	Acrylic body; Buna-N O-ring (fluoroelastomer available); nickel-plated brass metal parts (SS optional); float SS, black glass, aluminium or K monel depending on range
Temperature & Pressure Limits	Without valve: 100 psig (6.9 bar) at 150 °F (65 °C) or 150 psig (10 bar) at 100 °F (38 °C); with valve: 100 psig (6.9 bar) at 120 °F (48 °C)
Mounting	Vertical
Weight	4.0 to 4.8 oz (0.11 to 0.14 kg)
Approvals	RoHS II (EU Directive 2011/65/EU)

Attractive design with bodies that are cut and precisely machined from transparent, solid acrylic blocks permits full visual examination.
Improved reading accuracy because to the float's distinct appearance against a smooth white background.
With direct reading scales that are hot stamped into the plastic, there is no need for difficult conversions, and the product's operational life is extended.
High repeatability due to tapered bores that are precisely machined.
Reasonably priced installation with choices for back or end connections and metal mounting inserts that may be directly supported by system pipes.
