ETI 133-222 | General Purpose Penetration Probe | Type K, 5 m PFA Lead

Name: ETI 133-222 | General Purpose Penetration Probe | Type K, 5 m PFA Lead
Brand: eti
SKU: 133-222
Availability: InStock

Part Number : 133-222

ETI 133-222 is the type K version of ETI's general purpose penetration probe, fitted with a 5 m PFA-insulated lead so the logger can sit some distance from the measuring point. The Ø3.3 x 100 mm stem covers -75 to 250 °C and is recommended for ThermaData TD2TC WiFi loggers. ETI lists this probe with 1, 3, 5 or 10 m leads, so the cable can be matched to the installation.

Key features

Type K thermocouple, accuracy ±0.5 °C (0 to 100 °C)
5 m lead with PFA insulation
Response time under 5 seconds
Ø3.3 x 100 mm penetration stem
Recommended for ThermaData TD2TC WiFi loggers

Availability: in stock

Specifications

Part Number	133-222
Brand	ETI
Sensor	Type K thermocouple
Lead Length	5 m
Lead Insulation	PFA
Probe Dimensions	Ø3.3 x 100 mm
Temperature Range	-75 to 250 °C
Accuracy	±0.5 °C (0 to 100 °C)
Response Time	Less than 5 seconds
Recommended For	ThermaData TD2TC WiFi loggers
