FUJI FG-6H | Straight Wheel Grinder Series | 150 mm Wheels, 1040 W, 6300 rpm
Part Number : FG-6H
The FUJI FG-6H straight wheel grinder series is designed for 150 mm grinding wheels, running at 6300 rpm with a 1040 W (1.39 hp) motor. A centrifugal speed governor controls air pressure to keep the working speed steady. Rolling throttle and locking lever handles are offered with PT and NPT inlets.
Key features
- Type 1 wheels, 150 mm, 25 mm thick
- 5/8-11 UNC output spindle thread
- Air consumption 20 l/s / 42 cfm at load
- 3/8 in air inlet; 12.7 mm minimum hose
- Weight 3.4 to 3.5 kg; length 434 or 531 mm
- Sound pressure 83 dB(A); vibration below 2.5 m/s²
For pricing, please contact our experts.
