ifm IE5202, Inductive Threaded Barrel Proximity Sensor, M8, 2 mm Detection, PNP/NPN NO/NC, 5 → 36 V dc

Name: ifm IE5202, Inductive Threaded Barrel Proximity Sensor, M8, 2 mm Detection, PNP/NPN NO/NC, 5 → 36 V dc
Brand: ifm
SKU: IE5202
Availability: OutOfStock

Part Number : IE5202

Availability: Sold out

Detailed Description
Specifications

The ifm electronic inductive sensor is engineered to deliver exceptional performance in diverse industrial applications. With a robust threaded design and a compact form factor, it is optimally suited for tight spaces, ensuring reliable detection. The sensor operates within a wide voltage range and offers selectable output functions, enhancing its versatility. Built to withstand challenging conditions, it boasts an impressive IP67 protection rating, making it ideal for environments where dust or moisture are prevalent. Furthermore, the incorporation of short-circuit and overload protection ensures long-term reliability while safeguarding connected equipment. This sensor is an essential choice for professionals seeking precision and durability in their automation projects.

Particularly space-saving design
For use where space is restricted
Space-saving connection technology
Very high switching frequency
Output function normally open or normally closed programmable

Brand	ifm
Thread Size	M8
Sensor Technology	Inductive
Body Style	Threaded Barrel
Detection Range	2 mm
Digital Switching Output Type	PNP/NPN
Output Function	NO/NC
Connection Type	Pre-Cabled
Cable Length	2m
Supply Voltage	5 → 36 V dc
Length	50mm
IP Rating	IP67
Mounting Type	Non-Flush
Series	IE5
Switching Current	200 mA
Shielding	Unshielded
Switching Frequency	2 kHz
