ifm TS325A | RTD Sensor | Probe, +80°C

Name: ifm TS325A | RTD Sensor | Probe, +80°C
Brand: ifm
SKU: TS325A
Availability: InStock

Part Number : TS325A

The ifm TS325A is a rtd sensor with process connection Probe, sensor type PT100 and probe length 40mm.

Sensor Type: PT100
Probe Length: 40mm
Probe Diameter: 5mm
Maximum Temperature Sensed: +80°C
Termination Type: Cable
Cable Length: 3m
Process Connection: Probe
Hazardous Area Certification: ATEX

Availability: low stock

Detailed Description
Specifications
Downloads

ifm Electronic TR Series Temperature Transmitter

Ifm Electronic TR series temperature sensors evaluation unit is a universal control and display unit for connection of Pt100 / Pt1000 sensors. TR series sensors automatically detects whether two, three or four wire sensors are connected. The measuring range has freely scalable parameters that can bet set via an integrated IO-Link interface.

A simple three push button operation with integrated display allows switching states to be highlighted. The sensor head can be rotated and offers optimum readability from any position.

Features and Benefits

IO-Link interface
4-digit alphanumeric display
LED status indicators
IP67 Rated
Flexible installation

Brand	ifm
Sensor Type	PT100
Probe Length	40mm
Probe Diameter	5mm
Minimum Temperature Sensed	-20°C
Maximum Temperature Sensed	+80°C
Termination Type	Cable
Cable Length	3m
Process Connection	Probe
Hazardous Area Certification	ATEX
Response Time	10 (T09) s, 4 (T05) s
