ifm UGT203 | Ultrasonic Proximity Sensor | 1.6 m, NO/NC

Name: ifm UGT203 | Ultrasonic Proximity Sensor | 1.6 m, NO/NC
Brand: ifm
SKU: UGT203
Availability: InStock

Part Number : UGT203

The ifm UGT203 is an ultrasonic proximity sensor with detection range 1.6 m, output function NO/NC and supply voltage 10 → 30 V dc.

Thread Size: M18
Sensor Technology: Ultrasonic
Body Style: Threaded Barrel
Detection Range: 1.6 m
Digital Switching Output Type: PNP
Output Function: NO/NC
Connection Type: M12
Supply Voltage: 10 → 30 V dc

Availability: low stock

Detailed Description
Specifications
Downloads

UGT200 Series Diffuse Ultrasonic Sensors

IFM Electronics UGT200 series diffuse ultrasonic sensors offer an alternative sensing type for long ranges and difficult surfaces. The UGT200 series are able to operate reliably with heavy soiling, allowing them to be used where photoelectric sensors meet their limits.

Ultrasonic sensors transmit and receive sound waves in the ultrasonic range. Objects to be detected reflect the sound waves and distance information is determined via a time of flight measurement. Ultrasonic sensors are able to detect various object types, including colour or transparent objects or objects with a surface shine.

Features and Benefits

M18 Plastic housing
Digital and analogue output
Vibrating sound transducer reduces the deposit of dirt
Wide sensing range
Easy setting via wire or button teach

IFM Electric Ultrasonic Sensors

Brand	ifm
Thread Size	M18
Sensor Technology	Ultrasonic
Body Style	Threaded Barrel
Detection Range	1.6 m
Digital Switching Output Type	PNP
Output Function	NO/NC
Connection Type	M12
Supply Voltage	10 → 30 V dc
Length	97.5mm
IP Rating	IP67
Housing Material	Epoxy Glass Ceramic, PBT, Polyamide
Maximum DC Voltage	30V
Minimum Operating Temperature	-20°C
Maximum Operating Temperature	+70°C
Switching Frequency	3 Hz
Standards Met	CE, cULus, cULus Recognised, EN 55011, EN 60068-2-27, EN 60068-2-6, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, UL
Short Circuit Overload Protection	Yes
Maximum Switching Frequency	3Hz
Communication Protocol	IO-LINK
Switching Current	55 mA
