Micronics LIT-25 | Level Indicating Transmitter, Non-Contacting Ultrasonic | 10 m Range, 4–20 mA
Part Number : LIT-25
The Micronics LIT-25 Level Indicating Transmitter monitors liquid level in chemical storage tanks, sumps, reservoirs and lagoons with a non-contacting ultrasonic sensor mounted at the top of the tank; an optional pressure sensor is also listed. The standard sensor covers tanks up to 10 m high, and a built-in temperature probe compensates for changes in the speed of sound. The display enclosure can be mounted where operators can see it and calibrated from its 2-button keypad without climbing the tank.
Key features
- Isolated 4–20 mA output (1000 ohm) for direct connection to a PLC or controller
- Signal relay programmable for level alarm, pump control, temperature alarm or echo loss
- Large 4-digit LCD showing level or range in percent, inches or cm
- Accuracy ±0.25% of range or 2 mm, whichever is greater
- Output simulation and adjustable damping; self-testing
- Watertight, dust tight NEMA4X (IP67) enclosure; intrinsically safe sensor option
For pricing, please contact our experts.
