Mitutoyo 172-868E | Profile Projector | PH-3515F, 254 x 152 mm XY
Part Number : 172-868E
With 254 x 152 mm of XY stage travel and a 353 mm screen, the Mitutoyo PH-3515F (172-868E) vertical profile projector measures contours and angles through linear encoders at 0.001 mm resolution.
- XY travel 254 x 152 mm on a 450 x 146 mm stage
- Max. stage load 45 kg, workpiece height up to 235 mm
- Effective screen diameter 353 mm
- Linear encoder, 0.001 mm resolution; on-screen angle to 1' / 0.01°
- Magnification accuracy ±0.1% contour, ±0.15% surface illumination
- Quick release on X axis; 10X lens standard
Free UAE shipping available
For pricing, please contact our experts.
