Mitutoyo 7223A | Dial Indicator Depth Gauge | 0–10 mm, 0.01 mm grad
Part Number : 7223A
The Mitutoyo 7223A is a dial indicator depth gauge with a 0–10 mm range, 0.01 mm graduation and ±0.015 mm accuracy. Its kit includes five extension rods for reaching deeper features.
- 7223A stroke 10 mm, base Ø25 mm with 5 µm flatness
- Extension rods supplied with the 7223A: 10, 20, 30, 30 and 100 mm
- Fitting a contact point of a different size from the standard one may change the 7223A measuring range
- If a contact point is too large for the plunger hole in the base, zero-setting is not possible
- Flat contact points (flat/needle or carbide-tipped) need parallelism adjustment to the 7223A base face
