OMRON B3S-1000 | Button Tactile Switch | 6.6 x 6 mm, 1.57 N, Surface Mount
Part Number : B3S-1000
Needing 1.57 N to actuate, the OMRON B3S-1000 cream button tactile switch measures 6.6 x 6 mm and carries a 50 mA at 24 V DC contact rating. Rated values for the B3S-1000 include a mechanical life of 500,000 operations and an operating temperature range of -25 to +70 °C.
- Contact configuration: SPST
- Actuator length: 0.55 mm
- Height: 4.3 mm
- Switch operation: Momentary
- Mounting: surface mount
For pricing, please contact our experts.
Surface Mount Tactile Switch
All switches have a contact configuration of SPST N/O
Sealed construction
Tactile feedback
Dielectric strength: >500Vac/1 min
Insulation resistance: >100MΩ (250Vdc)
Sealed for immersion washing after soldering
Suitable for reflow soldering
Reflow temperature: 235°C, 10 secs max
Tactile feedback
Dielectric strength: >500Vac/1 min
Insulation resistance: >100MΩ (250Vdc)
Sealed for immersion washing after soldering
Suitable for reflow soldering
Reflow temperature: 235°C, 10 secs max
Note
Do not use chlorinated or aqueous solvents for cleaning
