OMRON D40Z-1C2 | Magnetic Non-Contact Safety Switch | Cable, Plastic Housing

Name: OMRON D40Z-1C2 | Magnetic Non-Contact Safety Switch | Cable, Plastic Housing
Brand: OMRON
SKU: D40Z-1C2
Availability: InStock

Part Number : D40Z-1C2

Built in plastic, the OMRON D40Z-1C2 magnetic non-contact safety switch provides a cable connection. Further specifications: a 24 V dc supply, a coded actuator (included), a 15 mm switching distance, IP67 protection and Safety Category 3.

Switching distance: 15 mm
Connection: cable
Housing: plastic
Protection rating: IP67
Safety category: 3
Supply voltage: 24 V dc

Availability: low stock

Detailed Description
Specifications
Downloads

D40 Non-Contact Switch

The D40 from Omron is a compact non-contact door switch with easy to see red/yellow LED status indicators. The actuator is smaller than the switch saving space, even when mounted with an L-bracket, the actuator's height will not hinder installation or operation. Mount from whichever side provides the easiest wiring path to enable mounting to all types of doors.

Easy-to-see 2 colour indicators
Mount from either side
Small actuator

Brand	Omron
Supply Voltage	24V dc
Housing Material	Plastic
Connection Type	Cable
Actuator Type	Coded
Safety Category	3
Sensor Principle	Magnetic
Actuator Included	Yes
Switching Distance	15 mm
Series	D40A
IP Rating	IP67
Width	16mm
Depth	48mm
Length	42mm
