OMRON E5DC-QX2DSM-002 | PID Temperature Controller | 48 x 48 mm, SSR Output, 24 V AC/DC
The OMRON E5DC-QX2DSM-002 is a 48 x 48 mm DIN-rail or panel-mount PID temperature controller from the E5DC series, fitted with two SSR/logic outputs and powered from 24 V AC/DC; its universal input handles platinum RTD, Pt100, thermocouple and analogue.
- Control: ON/OFF, PID, 2-PID
- Number of inputs: 1
- Terminals: screw terminal block
- Communication module available: yes
- Mounting: DIN rail or panel mount
- Detailed Description
- Specifications
- Downloads
Omron E5DC Series PID Temperature Controller, SSR Output, 24V AC/DC Supply Voltage - E5DC-QX2DSM-002
Features & Benefits
• SSR and linear current outputs provide versatile control options
• Universal input type accommodates thermocouples and resistance thermometers
• Adjustable ON/OFF and PID control methods optimise performance
• Removable screw terminal block simplifies maintenance tasks
• Integration with PLCs via programless communications for easy setup
Applications
• Used for precise monitoring and regulation of heating equipment
• Suitable for requiring PT100 thermocouple inputs
• Ideal for projects needing a robust and efficient solid state relay controller
What types of input does it support?
How can I connect it to a PLC?
What maintenance is recommended for optimal performance?
Does it allow for manual control?
What is the maximum load current capacity?
| Brand | Omron |
| Series | E5DC |
| Output Type | SSR, Solid State Relay, Logic |
| Supply Voltage | 24 V ac/dc |
| Size | 48 x 48 mm (1.89×1.89 in) |
| Number of Outputs | 2 |
| Control Type | ON/OFF, PID, 2-PID Controller |
| Input Type | Universal, Platinum Resistance Thermometer, PT100, Thermocouple, Analogue |
| Mounting Type | DIN Rail, Panel Mount |
| Termination Type | Screw terminal block |
| Number of Inputs | 1 |
| Communication Module Available | Yes |
