OMRON G5NB-1A4 DC5 | PCB Power Relay | 5 V DC Coil, 3 A, SPST

Name: OMRON G5NB-1A4 DC5 | PCB Power Relay | 5 V DC Coil, 3 A, SPST
Brand: OMRON
SKU: G5NB-1A4 DC5
Availability: InStock

Part Number : G5NB-1A4 DC5

OMRON G5NB-1A4 DC5: a PCB-mount G5NB series power relay driven by a 5 V DC coil, with an SPST contact arrangement and 3 A switching current. Further G5NB-1A4 DC5 details: a coil resistance of 125 Ω and non-latching operation.

Coil power: 200 mW
Number of poles: 1
Coil-to-contact isolation: 4 kV AC

Availability: low stock

Detailed Description
Specifications
Downloads

G5NB Series

Compact slim body (20.5x15.3x7.2mm) single pole relays with high isolation between coil and contacts
High withstand voltage rating of 10kV (1.2 x 50μs) between coil and contacts
Highly efficient magnetic circuit for high sensitivity (200 mW)
Tracking resistance: CTI>250

Approvals

UL, CSA, VDE

The Omron G5NB PCB Power Relay has 1-pole 3A Switching Capability and 10 kV Impulse Withstand Voltage. The G5NB PCB Power Relay has application such as Water heaters, Refrigerators, Air conditioners, Home appliances and Small electric appliances.

Highly efficient magnetic circuit for high sensitivity (200 mW)
PCB terminals

Brand	Omron
Coil Voltage	5V dc
Contact Configuration	SPST
Mounting Type	PCB Mount
Switching Current	3A
Number of Poles	1
Series	G5NB
Latching	No
Coil Resistance	125Ω
Coil Power	200mW
Isolation Coil To Contact	4kV ac
