OMRON G5RL-K1A-EL-HA DC12 | PCB Mount Non-Latching Relay | 12 V DC Coil, 16 A, SPST

Name: OMRON G5RL-K1A-EL-HA DC12 | PCB Mount Non-Latching Relay | 12 V DC Coil, 16 A, SPST
Brand: OMRON
SKU: G5RL-K1A-EL-HA DC12
Availability: InStock

Part Number : G5RL-K1A-EL-HA DC12

The OMRON G5RL-K1A-EL-HA DC12 is a PCB-mount non-latching relay with a 12 V DC coil and SPST contacts rated at 16 A. Coil resistance is 192 Ω with 750 mW coil power, and coil-to-contact isolation is 10 kV.

SPST contact configuration, 1 pole
Number of coils: dual
OMRON G5RL-K series

Availability: low stock

Detailed Description
Specifications
Downloads

The Omron low profile power relay with 15.7 mm height, ideal for incorporation in miniature equipment's. Rated coil voltage is 12Vdc and use for home appliance according.

A wide variety of single pole, double pole, high-capacity (16 A) type and high-sensitivity type (250 mW) relays are available.
IEC/EN 60335-1 conformed. (-HA Model)
Satisfies ambient operating temperature requirement of 85°C and 105°C
Clearance and creepa

Brand	Omron
Coil Voltage	12V dc
Contact Configuration	SPST
Mounting Type	PCB Mount
Switching Current	16A
Number of Poles	1
Series	G5RL-K
Coil Resistance	192 Ω
Coil Power	750mW
Isolation Coil To Contact	10kV
Number of Coils	Dual
