OMRON G9TA-U1AP DC12 | PCB Mount Power Relay | 12 V DC Coil, SPST, 60 A

Name: OMRON G9TA-U1AP DC12 | PCB Mount Power Relay | 12 V DC Coil, SPST, 60 A
Brand: OMRON
SKU: G9TA-U1AP DC12
Availability: InStock

Part Number : G9TA-U1AP DC12

With a 12 V DC coil, the OMRON G9TA-U1AP DC12 power relay switches 60 A through SPST contacts. The listing for the G9TA-U1AP DC12 specifies PCB mounting.

Single coil
Switching current limits: 60 A AC / 60 A DC
Coil voltage: 12 V DC

Availability: low stock

Detailed Description
Specifications
Downloads

The Omron G9TA series of latching relay with 60 A high switching current and 12 Vdc coil voltage. Used for smart meter and PV inverter.

High power switching, Compact size
High magnetic latching force provides vibration resistance
Low contact resistance
PCB terminals type available
Conforms to UL 508 (Except PCB terminals type)

Brand	Omron
Coil Voltage	12V dc
Contact Configuration	SPST
Mounting Type	PCB Mount
Switching Current	60A
Maximum Switching Current AC	60 A
Maximum Switching Current DC	60 A
Number of Coils	Single
