OMRON K8DS-PM1 | K8DS-PM Phase and Voltage Monitoring Relay | 3-Phase, 200 to 240 VAC, SPDT
Part Number : K8DS-PM1
The K8DS-PM1 is a three-phase voltage and phase-sequence phase-loss relay from the OMRON K8DS-PM series, in a slim 17.5 mm wide case. It monitors a three-phase, three-wire supply at 200, 220, 230 or 240 VAC. It protects motors and equipment from phase loss, reverse phase and abnormal voltage.
Key features
- Monitors phase sequence, phase loss, overvoltage and undervoltage
- Rated input 200, 220, 230 or 240 VAC, three-phase three-wire
- Over/undervoltage thresholds adjustable from -30% to +25% of rated voltage
- One SPDT output relay, 5 A at 250 VAC / 30 VDC (resistive)
- Phase-sequence operating time 0.1 s, phase-loss operating time 0.1 s max.
- Slim 17.5 mm wide case
