PT100 immersion probe ifm electronic TT2281

Name: PT100 immersion probe ifm electronic TT2281
Brand: ifm
SKU: TT2281
Availability: OutOfStock

Part Number : TT2281

The TT2281 Pt100 immersion probe from ifm is a resistance thermometer that carries out precise measurements in a temperature range from -40-150 °C. The high-grade stainless steel housing with high protection rating IP68/IP69K has an installation length of 250 mm. The robust sensor probe has a diameter of 6 mm. Thanks to the latest technologies and a thin sensor tip the TT2281 Pt100 screw-in sensor features extremely fast response times of T05 = 1 s and T09 = 3 s. The long life and the high pressure rating for individual applications distinguish this resistance thermometer. The TT2281 Pt100 immersion probe with M12 connector is ideal for temperature measurements in industrial applications.

Availability: Sold out

Specifications
Features
Downloads

Accuracy	+/- (0,15 K + 0,002 x \|t\|)k
Ambient temperature	-25 °C to 80 °C
Material	stainless steel (1.4404 / 316L)
Measuring range	-40 °C to 150 °C
Protection class	III
Storage Temperature	-40 °C to 100 °C
System	gold-plated contacts
Weight	52.1g

Precise temperature measurement in containers, tanks and pipes
For the connection to an evaluation unit
Very short response time for use in processes with fast temperature fluctuations
Robust stainless steel housing with high protection rating and high pressure resistance
Variable process connection using adapters
