Aim-TTi PSA6005 | Handheld RF Spectrum Analyzer | 10MHz to 6.0GHz

Name: Aim-TTi PSA6005 | Handheld RF Spectrum Analyzer | 10MHz to 6.0GHz
Brand: Aim Tti
SKU: PSA6005
Availability: InStock

Part Number : PSA6005

Covering 10MHz to 6000MHz, the Aim-TTi PSA6005 is the widest-range PSA Series 5 handheld analyzer. It packs this coverage into a 0.56kg battery-powered unit, giving RF engineers and technicians a portable instrument for site surveys and troubleshooting. Twin markers with smart peak tracking speed up signal identification.

Key features

10MHz to 6000MHz frequency range
Resolution bandwidths 300Hz to 10MHz
-120dBm typical noise floor
Live, view and reference traces in contrasting colours
Unlimited storage for waveforms, set-ups and screens
More than 3 hours from the lithium-ion battery

Availability: low stock

Free UAE shipping available

Detailed Description
Specifications
Features
Downloads

Aim-TTi Spectrum Analyser, 6 GHz Maximum Frequency, USB Interface Type - PSA6005

This spectrum analyser from Aim-TTi, the PSA6005, offers advanced features and portability for users in the automation, electronics, electrical, and mechanical industries. With a frequency range of 10 MHz to 6 GHz, this handheld device provides precise analysis and measurement capabilities for a wide range of applications.

Features & Benefits

10 MHz to 6 GHz frequency range for comprehensive analysis
Handheld design for portability and convenience
Battery-operated with more than 3 hours of continuous operation
USB connectivity for data transfer and storage
High resolution colour display with detailed information
Waveform demodulation for AM and FM/PM signals
Unlimited data storage for waveforms, set-ups, and screen images
Compact and lightweight design for easy handling

Applications

Reliable for RF signal analysis
Ideal for frequency measurement
Recommended for signal modulation analysis
Can be used for spectrum monitoring
Suitable for antenna testing
Essential for wireless communication analysis

Can it store thousands of waveforms and instrument set-ups?

Yes, it can store thousands of waveforms, instrument set-ups, and complete screen images.

Will it provide precise frequency measurement?

The spectrum analyser offers accurate frequency measurement for detailed analysis of RF signals.

Is it suitable for antenna testing applications?

Yes, it is ideal for antenna testing with its wide frequency range and high-resolution display.

Can it be used for wireless communication analysis?

Yes, the spectrum analyser is suitable for analysing wireless communication signals with its advanced features.

Part Number	PSA6005
Brand	Aim-TTi
Frequency Range	10 MHz to 6000 MHz
RBW	300 Hz to 10 MHz (1:3:10)
Noise Floor	-120 dBm typical
Frequency Counter	Down to 10 Hz resolution
Interfaces	USB (flash drive and PC)
Battery	Li-ion, >3 hours
Weight	0.56 kg

A portable radio frequency analyzer with a diverse set of capabilities.
The frequency range is from 10MHz to 6000MHz.
Resolution bandwidths ranging from 300Hz to 10MHz (1:3:10).
At -40dBm ref. level/ 10kHz, the typical noise floor is -120dBm.
Frequency counter with a resolution of 10Hz.
AM and FM audio demodulation in Zero Span mode.
Normal, Peak Hold, and Average trace modes are available.
The Live, View, and Reference traces are shown in different colours.
TFT touchscreen display (4.3").
View twin markers with absolute and difference value readouts.
View measurements in dBm, dBV, mV, and W.
Preset frequencies.
Intelligent marker movement with peak tracing.
Auto-Find function: sets sweep parameters based on the highest detected signal.
Storage of independent states.
Waveforms, set-ups, and screens can be saved indefinitely.
Internal memory is 1.8GB.
