ASCO 18900002.24/50-60, Solenoid Valve , 3 port(s) , Normally Closed, 24 V ac, G 3/4in

Name: ASCO 18900002.24/50-60, Solenoid Valve , 3 port(s) , Normally Closed, 24 V ac, G 3/4in
Brand: Asco
SKU: 18900002.24/50-60
Availability: OutOfStock

Part Number : 18900002.24/50-60

Availability: Sold out

Detailed Description
Specifications

The Asco Solenoid valve is part of the direct-operated Series 189 and features a normally open, three-way configuration. It is designed for subbase mounting and has a nominal diameter of 1.2 millimeters (6B). The valve operates at 24V with a frequency range of 50-60Hz. It is equipped with a manual override for enhanced control in various applications.

Includes Coils 4304416
Manual override provided

Brand	Asco
Supply Voltage	24 V ac
Number of Ports	3
Connection Size	G 3/4in
Connection	`G 3/4
Operation	Direct
Default Valve Position	Normally Closed
Suitable Applications	Air, Inert Gas
Type	3/2
Body Material	Polyamide
Series	189
Maximum Working Pressure	10 bar
Operating Temperature Range	-10 To 60 °C
Connection Gender	Female
Thread Standard or Connection Type	G
Maximum Operating Temperature	+60°C
Minimum Operating Temperature	-10°C
