ASCO 18900011.230/50-60, Solenoid Valve , 3 port(s) , NO, 230 V, 3/4in

Name: ASCO 18900011.230/50-60, Solenoid Valve , 3 port(s) , NO, 230 V, 3/4in
Brand: Asco
SKU: 18900011.230/50-60
Availability: OutOfStock

Part Number : 18900011.230/50-60

Availability: Sold out

Detailed Description
Specifications
Downloads

The Asco solenoid valve is engineered for reliability and performance in fluid control applications. Crafted with an ISO 15218 interface, it easily integrates into various setups, ensuring seamless operations. The valve operates efficiently under a wide temperature range, making it suitable for numerous environments. Its compact and lightweight design simplifies installation, while AC/DC interchangeability of the solenoid operator enhances flexibility without the need for disassembly. The incorporation of visual indication and peak voltage suppression conforming to 'UL' standards signifies its safety and compliance, making it a trusted choice for professionals. Moreover, the device is designed for manual operation as standard, catering to diverse requirements in automated systems and pilot applications. Featuring robust construction and materials, it assures long-lasting durability and effective performance in demanding conditions.

Efficient response time ensures quick actuation
M12 connector enhances connectivity options
Durable materials withstand harsh operating conditions
Flexible mounting options support various installation scenarios
Manual operator provides alternative control when needed
Seals are designed for optimal performance with air and inert gas
AC/DC functionality caters to diverse system requirements

Brand	Asco
Supply Voltage	230 V
Number of Ports	3
Connection Size	3/4in
Connection	3/4 in G
Operation	Direct
Default Valve Position	NO
Suitable Applications	Air, Inert Gas
Type	Solenoid
Orifice Diameter	1.2mm
Body Material	Polyamide
Series	189
Maximum Working Pressure	10 bar
Operating Temperature Range	-10 → +60 °C
Servo Assist	No
Maximum Operating Temperature	+60°C
Minimum Operating Temperature	-10°C
Thread Standard or Connection Type	G
Flow Factor Kv	1.2L/min
