ASCO 18900070.48/DC, Solenoid Valve , 3 port(s) , NC, 48 V, 3/4in

Name: ASCO 18900070.48/DC, Solenoid Valve , 3 port(s) , NC, 48 V, 3/4in
Brand: Asco
SKU: 18900070.48/DC
Availability: OutOfStock

Part Number : 18900070.48/DC

Availability: Sold out

Detailed Description
Specifications

The Asco Solenoid Valve is designed for maximum efficiency in demanding applications. This solenoid valve features a robust design with a CNOMO interface, making it ideal for piloting applications in compact and lightweight installations. The versatility of being able to interchange AC and DC solenoid operators without disassembly enhances its practicality. With an extensive operating temperature range and compliance with critical EU directives, this product demonstrates reliability and safety. Users can benefit from flexible installation options, including pad mounting on single or joinable subbases, ensuring easy adaptations to existing setups. Built for durability, it ensures long-lasting performance even in challenging environments.

CNOMO pad-mount design simplifies installation procedures
AC/DC interchangeability supports versatility in operations
Maintenance-free solenoid operators contribute to reduced downtime
Compatible with visual indication connectors for enhanced functionality
Fulfils rigorous EU standards for reliability and safety
Adaptable to a variety of subbase options for flexible usage
High-quality materials in construction ensure longevity and robustness
Resilient seals and insulation contribute to effective operation in varying conditions

Brand	Asco
Supply Voltage	48 V
Number of Ports	3
Connection Size	3/4in
Connection	3/4 in G
Operation	Direct
Default Valve Position	NC
Suitable Applications	Air, Inert Gas
Type	Solenoid
Orifice Diameter	1.2mm
Body Material	Polyamide
Series	189
Maximum Working Pressure	10 bar
Operating Temperature Range	-10 → +60 °C
Servo Assist	No
Thread Standard or Connection Type	G
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+60°C
Flow Factor Kv	1.2L/min
