ASCO 18900075.24/DC, Solenoid Valve , 3 port(s) , NO, 24 V, 3/4in

Client Protection

Dedicated Support

Client Protection

Dedicated Support

ASCO 18900075.24/DC, Solenoid Valve , 3 port(s) , NO, 24 V, 3/4in

Name: ASCO 18900075.24/DC, Solenoid Valve , 3 port(s) , NO, 24 V, 3/4in
Brand: Asco
SKU: 18900075.24/DC
Availability: OutOfStock

Part Number : 18900075.24/DC

Availability: Sold out

Detailed Description
Specifications

The Asco solenoid valve is engineered to deliver exceptional performance across various applications. With a compact and lightweight design, it simplifies installation on both single and joinable subbases, making it an ideal choice for piloting applications. This innovative valve features AC/DC interchangeability without the need for disassembly, ensuring seamless operation. Its M12 version offers a visual indication and peak voltage suppression, adhering to UL standards for added safety. The solenoid valve complies with all relevant EU directives, guaranteeing reliability and functionality in diverse environments. Designed for versatility, it performs well within a wide temperature range, demonstrating its capability to handle different operational demands.

The compact size allows for flexible installation options
AC/DC interchangeable solenoid operators enhance operational efficiency
Visual indication and peak voltage suppression are standard in the M12 version
Constructed from durable materials for long-term reliability
Easy manual override ensures operational continuity during power loss
Complies with stringent EU directives for safety and performance
Available with various connector specifications to match installation needs
Can handle extensive pressure and temperature ranges for diverse applications

Brand	Asco
Supply Voltage	24 V
Number of Ports	3
Connection Size	3/4in
Connection	3/4 in G
Operation	Direct
Default Valve Position	NO
Suitable Applications	Air, Inert Gas
Type	Solenoid
Orifice Diameter	1.2mm
Body Material	Polyamide
Series	189
Maximum Working Pressure	10 bar
Operating Temperature Range	-10 → +60 °C
Servo Assist	No
Thread Standard or Connection Type	G
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+60°C
Flow Factor Kv	1.2L/min
