AVENTICS 0822206405 | Pneumatic Piston Rod Cylinder | 125 mm Bore, 125 mm Stroke, TRB, up to +150 °C

Name: AVENTICS 0822206405 | Pneumatic Piston Rod Cylinder | 125 mm Bore, 125 mm Stroke, TRB, up to +150 °C
Brand: Aventics
SKU: 0822206405
Availability: InStock

Part Number : 0822206405

Bore 125 mm and stroke 125 mm are the defining sizes of the AVENTICS 0822206405, a double-acting TRB series pneumatic piston rod cylinder. Rated from -10 to +150 °C, the 125/125 mm build follows ISO 15552.

Size 125 x 125 mm (bore x stroke) (0822206405)
10 bar maximum pressure on the 125 mm stroke unit
Rated -10 to +150 °C on the 125 mm stroke unit
Piston rod thread: male for the 125 mm bore
Port and pneumatic connection: G 1/2 on the 125 mm stroke unit
Cushioning: pneumatic for the 125 mm bore

Availability: low stock

Detailed Description
Specifications
Downloads

The Aventics Tie Rod Cylinder revolutionises industrial applications with its robust design and exceptional performance. Engineered in accordance with ISO 15552 standards, this series TRB product stands out in sectors requiring heavy-duty solutions, such as automotive, mining, and machinery. The cylinder features pneumatic adjustable cushioning, ensuring smooth and controlled motion, essential for precision tasks. Built to endure extreme temperatures from -10 °C to 150 °C, it thrives in challenging environments, while its stainless steel piston rod guarantees durability and reliability.

Constructed from high quality materials for lasting performance
Compatible with ISO 15552 standards ensuring universal fit
Offers a robust design to withstand harsh working conditions

Brand	AVENTICS
Manufacturer Series	TRB
Model Number p	0822206405
Action	Double
Bore	125mm
Stroke	125mm
Pneumatic Connection	G 1/2
Port Connection	G 1/2
Piston Rod Thread Gender	Male
Cushioning Type	Pneumatic Cushioning
Maximum Operating Pressure	10 bar
ISO Standard	15552
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+150°C

AVENTICS 0822206405 | Pneumatic Piston Rod Cylinder | 125 mm Bore, 125 mm Stroke, TRB, up to +150 °C

DOWNLOAD CATALOG

0822206405 Datasheet - 0822206405 A700000012559447

0822206405 Datasheet - 0822206405 A700000012561603
