AVENTICS 0822334510 | MNI Roundline Pneumatic Cylinder | 25 mm Bore, 320 mm Stroke, Double Acting

Name: AVENTICS 0822334510 | MNI Roundline Pneumatic Cylinder | 25 mm Bore, 320 mm Stroke, Double Acting
Brand: Aventics
SKU: 0822334510
Availability: InStock

Part Number : 0822334510

AVENTICS 0822334510 delivers 320 mm of stroke through a 25 mm bore as part of the MNI Roundline cylinder line. AVENTICS documents pneumatic cushioning, G 1/8 ports and ISO 6432 conformity for 0822334510.

320 mm stroke, 25 mm bore
MNI series double-acting cylinder, part 0822334510
Part 0822334510 pressure rating: 10 bar maximum
Part 0822334510 temperature range: -25 to +80 °C
Part 0822334510 rod thread: male

Availability: low stock

Detailed Description
Specifications
Downloads

The Aventics Mini Cylinder from the Series MNI exemplifies precision engineering designed specifically for diverse industrial applications. The robust construction ensures a long service life, making it ideal for general machine construction tasks. Engineered to conform with ISO 6432 standards, this double-acting cylinder features a compact design without compromising on performance. It is equipped with elastic cushioning for smooth operation and includes a magnetic piston, ensuring enhanced functionality.

Compatible with ATEX certification for hazardous locations
Standardised connection ports facilitate easy integration
Wide temperature range allows for versatility in different conditions
Lightweight design assists in reducing overall system weight

Brand	AVENTICS
Manufacturer Series	MNI
Model Number p	0822334510
Bore	25mm
Action	Double
Stroke	320mm
Pneumatic Connection	G 1/8
Port Connection	G 1/8
Piston Rod Thread Gender	Male
Cushioning Type	Pneumatic Cushioning
Maximum Operating Pressure	10 bar
ISO Standard	ISO 6432
Maximum Operating Temperature	+80°C
Minimum Operating Temperature	-25°C

AVENTICS 0822334510 | MNI Roundline Pneumatic Cylinder | 25 mm Bore, 320 mm Stroke, Double Acting

DOWNLOAD CATALOG

0822334510 Datasheet - 0822334510 A700000012558090

0822334510 Datasheet - 0822334510 A700000012571570
