AVENTICS 0822395604 | KPZ Compact Pneumatic Cylinder | 50 mm Bore, 25 mm Stroke, Female Rod Thread
The KPZ compact cylinder 0822395604 by AVENTICS combines a 50 mm piston bore with 25 mm of travel and is double acting, with a female thread at the rod end. Air is supplied through G 1/8 connections, and the rated limit is 10 bar at 50 mm bore.
- 50 mm piston diameter, 25 mm stroke length
- Rod end with female thread (50 mm bore)
- Ports for the female-thread 50 mm unit: G 1/8
- Elastic cushioned, double-acting 25 mm stroke design
- Rated to 10 bar and -20 to +80 °C (50 x 25 mm)
- Detailed Description
- Specifications
- Downloads
Elastic cushioning reduces impact and prolongs operational lifespan
Compact form factor allows for seamless integration into tight spaces
Wide temperature range guarantees optimal performance in varying environments
Equipped with a magnetic piston for easy position sensing
Integrated with an optional ATEX rating for use in explosive environments
Constructed from high-quality materials ensuring long-lasting durability
Adaptable piston rod thread supports diverse mounting configurations
Low oil content requirement caters to specific application needs
Customisation options available through an online configurator enhance application versatility
| Brand | AVENTICS |
| Manufacturer Series | KPZ |
| Model Number P | 0822395604 |
| Action | Double |
| Bore | 50 mm (1.97 in) |
| Stroke | 25 mm (0.984 in) |
| Pneumatic Connection | G 1/8 |
| Port Connection | G 1/8 |
| Cushioning Type | Elastic |
| Maximum Operating Pressure | 10 bar (145 psi) |
| Maximum Operating Temperature | +80 °C (176 °F) |
| Minimum Operating Temperature | -20 °C (-4 °F) |
| Piston Rod Thread Gender | Female |
