AVENTICS R412009358 | Air Preparation Reservoir | For AS5-CBS

Name: AVENTICS R412009358 | Air Preparation Reservoir | For AS5-CBS
Brand: Aventics
SKU: R412009358
Availability: InStock

Part Number : R412009358

Listed for the AS5-CBS series, the AVENTICS R412009358 is a reservoir within the air preparation accessories range. The source lists other reservoirs for AS5-CBS with the same data, so check part number R412009358 against the documentation for your unit.

Accessory type: reservoir
For manufacturer series: AS5-CBS
Category: air preparation accessories
Brand: AVENTICS

Availability: low stock

Detailed Description
Specifications
Downloads

The Aventics Reservoir is designed for industrial applications, featuring a die-cast zinc metal reservoir with an inspection glass window. The lubricator reservoir has a volume of 181 cm³ and is suitable for use with compressed air and oil. It weighs 0.68 kg, with the reservoir made from durable die-cast zinc and the seals crafted from acrylonitrile butadiene rubber.

Minimum working pressure 0 bar
Maximum working pressure 16 bar
Minimum ambient temperature -10 °C
Maximum ambient temperature 50 °C
Minimum medium temperature -10 °C
Maximum medium temperature 50 °C
