AVENTICS R422001204 | Double-Acting CCI Compact Cylinder | 25 mm Bore, 50 mm Stroke, M5 Port, 279 g
25 mm bore, 50 mm stroke: these are the defining sizes of AVENTICS R422001204, a CCI-series compact cylinder working in double-acting mode. Rated at 10 bar maximum, the 25 mm bore, 50 mm stroke model uses M5 air connections and rubber cushioning and suits operating temperatures of -20 °C to +80 °C. Listed size is 94.5 x 40.3 x 40.3 mm, with a weight of 279 g.
- Bore x stroke: 25 x 50 mm
- Double-acting, CCI series
- M5 pneumatic connection
- Cushioning type: rubber
- Pressure up to 10 bar; -20 °C to +80 °C
- 94.5 x 40.3 x 40.3 mm, 279 g
- Detailed Description
- Specifications
- Downloads
Series CCI External Piston Rod Thread
| Brand | AVENTICS |
| Manufacturer Series | CCI |
| Action | Double |
| Bore | 25 mm (0.984 in) |
| Stroke | 50 mm (1.97 in) |
| Port Connection | M5 |
| Cushioning Type | Rubber |
| Maximum Operating Pressure | 10 bar (145 psi) |
| Maximum Operating Temperature | +80 °C (176 °F) |
| Minimum Operating Temperature | -20 °C (-4 °F) |
| Dimensions | 94.5 x 40.3 x 40.3 mm (3.72×1.59×1.59 in) |
| Width | 40.3 mm (1.59 in) |
| Height | 40.3 mm (1.59 in) |
| Length | 94.5 mm (3.72 in) |
| Weight | 279g |
